QC11k-6*3200 Shearing Machine 3.2m, CNC Shearing Machine 6mm

Construction

1. All-steel welded structure, vibration to eliminate stress,high strength,good rigidity.

2. Hydraulic transmission,three-point support rolling guide（Lower eccentric shaft, front pivot shaft, upper eccentric shaft）makes blade up and down into linear motion,accumulator return,rectangular blade, and four sides can be use.

3. Shear angle can be adjusted, different thickness use different shear angle. Reduced shear angle can decrease the deformation of sheet，increase the shear speed; Also can increase shear angle to increase the shear force，Adopt fast and flexible electric gap adjustment mechanism for cutting accuracy.

4. Equipped with lighting alignment device, easy to shearing.

5. Back-gauge size and shear times controlled by CNC system control，back-gauge using high-precision ball screw, running stable, accurate positioning. CNC system using frequency control technology, with multi-step programming function, simple operation and convenient.

6. Equipped safety protection device at machine left, right and back. Electric cabinets equipped with open door power off device, before and after have emergency switch device. Foot pedal equipped with protection cover to ensure working safety.
