DIN 1.2842 / AISI O2 Tool Steel Round & Flat

high quality
DIN 1.2842 / AISI O2 Tool Steel Round & Flat

Description

Download

DIN 1.2842 / AISI O2 Tool Steel for Punches, Dies for Blanking and Punching

Equivalence

AISI / SAE

DIN / W.Nr

JIS

GB

O2

1.2842

----

9Mn2V+Cr


Chemical Composition (%)

Steel Grade

C

Si

Mn

P

S

Cr

Mo

V

1.2842

0.85
0.95

0.10
0.40

1.80
2.20


0.030


0.030

0.20
0.50

----

0.05
0.15

O2

0.85
0.95


0.50

1.40
1.80


0.030


0.030


0.50


0.30


0.30


Dimensions

Shape

Thick / Dia. (mm)

Width (mm)

Round

8-700

/

Flat

1.6-200

20-1000

Block

150-600

200-1500


Delivery Condition
EAF+LF+VD, Hot rolled or Forged, Spheroidizing Annealed, Hardness≤220HB, Unmachined or Machined surface (Peeled, Turned, Milled, Grinded), UT 100% Passed

Characteristics
1. Cold work tool steel with high dimensional stability at heat treatment.
2. Very high cracking resistance. High machinability, medium thoughness and wear resistance.

Applications
Tools (punches) and dies for blanking, punching and similar operations; threading and wood working tools, machine knives for the pulp, paper and metal working industries; measuring tools and plastic mould dies.

Heat Treatment
Annealing
680 to 720°C
Slow controlled cooling in furnace at a rate of 10 to 20°C/hr down to approx. 600°C, further cooling in air. Hardness af ter annealing: Max. 220 HB.

Stress relieving
Approx. 650°C
Slow cooling in furnace; intended to relieve stresses set up by extensive machining, or in complex shapes. After through heating, hold in neutral atmosphere for 1-2 hours.

Hardening
790 to 820°C
Oil, salt bath (200 to 250°C) up to 20 mm thickness. Holding time after temperature equalization: 15 to 30 minutes. Obtainable hardness: 63 - 65 HRC

Tempering
Slow heating to tempering temperature immediately after hardening/time in furnace 1 hour for each 20 mm of work piece thickness, but at least 2 hours/cooling in air.For certain cases we recommend to reduce tempering temperature and increase holdingtime.


What we can offer?

We offer a wide range of steel products in a wide variety of dimensions and executions, acc.to the common international specifications or customerized.
Machining and heat treatment are available.
Also, we advise you in choosing the right materials.

Shape Available
Solid round bar
Flat bar
Square bar
Hexagon bar
Block
Plate
Sheet
Wire rod
Strip



AISI

DIN

JIS

Stock

Application

Hot Work Tool Steel

H11

1.2343

SKD6

Die Casting Dies,Extrusion Dies, Hammer Dies,
Ram Dies,
Forging Dies
etc.

H13

1.2344

SKD61

H10

1.2365

SKD7



——

1.2367

——



L6

1.2714 / 1.2713

SKT4

H12

1.2606

SKD62



H21

1.2581

SKD5

Cold Work Tool Steel

D3

1.2080

SKD1

Cutting Tools, Punching Tools, Shear Bladers, Reamers, Thread Rolling Dies, Calipers, Sockets etc.

——

1.2601

~SKD11

D2

1.2379

~SKD11

——

1.2379 MOD

DC53 (Daido)

D6

1.2436

——



O1

1.2510

SKS3

O2

1.2842

——



A2

1.2363

SKD12



S1

1.2550

——



S7

1.2357

——



——

1.2767

SKT6



L2

1.2210

——



Plastic
Mould Steel

P20

1.2311

——

      Mold Base,           Core & Cavity,         Bumper Mold             etc.

P20+Ni

1.2738

——

P20+S

1.2312

——

——

1.2316

——



420

1.2083

SUS420J2

——

——

NAK80 (Daido)

Alloy Steel

4120

25CrMo4 / 1.7218

SCM420



Shafts, Gears, Drillers, Chains, Bolts, Nuts, Pins, Suds, Keys, Bites, Crankshafts, Connecting Rods, Came, Couplings  etc.

4135

34CrMo4 / 1.7220

SCM435



4130

34CrMo4 / 1.7220

SCM430

4140

   42CrMo4 /        42CrMoS4 /                1.7225

SCM440

4142

41CrMo4 / 1.7223

SCM440



4145H

——

——



4330V

——

——



4340

34CrNiMo6 / 1.6582

SNCM439



5115

16MnCr5 / 16MnCrS5 / 1.7131





5120

20MnCr5 / 20MnCrS5 / 1.7147

SMnC420H



5140

41Cr4 / 41CrS4 / 1.7035

SCr440

8620

21NiCrMo2 / 1.6523

SNCM220



8640

40NiCrMo2-2 / 1.6546

SNCM240



——

18CrNiMo7-6 / 17CrNiMo6 / 1.6587

——



9840

36CrNiMo4 / 1.6511

——



E71400

41CrAlMo7-10 / 1.8509

SACM1



——

34CrAlNi7 / 1.8550

——



Bearing Steel

E52100

100Cr6 / 1.3505

SUJ2

Bearing, Shafts
etc.

——

100CrMn6 / 1.3520

——



——

100CrMo7-3 / 1.3536

——



Spring Steel

5155

55Cr3 / 1.7176

SUP9



Springs

6150

51CrV4 / 1.8159

SUP10



9261

60CrSi7 / 1.7108

——



Carbon Steel

1010

CK10 / C10E / 1.1121

S10C



Shafts, Chains, Bolts, Nuts, Pins, Suds, Keys, Bites, Came, Couplings  etc.

1020

C22 / 1.0402

S20C

1040

CK40 / C40E / 1.1186

S40C

1045

CK45 / C45E / 1.1191

S45C

1050

CK50 / C50E / 1.1206

S50C

1055

CK55 / C55E / 1.1203

S55C



1064

CK60 / C60E / 1.1221

S58C



High Speed Tool Steel

M2

1.3343

SKH51

Reamer,
      End-mill,
Hob, Cutter, Bite, Drill, Punch, Tap, Brooch
etc.

M7

1.3348

——



M42

1.3247

SKH59

M35

1.3243

SKH55

T1

1.3355

SKH2



T15

1.3202

——



T42

1.3207

SKH57




Note:
1). √ means we have stoc
2). Delivery Condition:
Smelting: EAF+LF+VD (+ESR)
Making: Hot rolled, Cold rolled, Forged, Cold Drawn
Heat Treatment: Untreated, Annealing, N+T, Q+T
Surface: Black, Peeled, Turned, Milled, Grinded, Polished
